Square and Round Pipe Laser Cutting Machine | CNC Tube Laser Cutter

The Fwincnc Square and Round Pipe Laser Cutting Machine, serving as a high-performance CNC Square Round Tube Laser Cutter and an advanced Automated Metal Pipe Laser Cutting System, represents a flagship Dual-Chuck Tube Laser Cutting Equipment on the market. Engineered as a heavy-duty Multi-Functional Pipe Laser Cutting Workstation and an ultra-precise Precision Square Round Tube Profiler, this versatile Industrial Metal Tube Laser Cutter Solution functions as a High-Speed CNC Pipe Cutting Tool to maximize output speeds. Built as a high-performance Versatile Profile Fiber Laser Cutter, this system establishes a highly Reliable Square Round Pipe Cutting Machine standard.

1.The software can cut multiple intersecting cylindrical holes of different directions and diameters on the main pipe, meeting the conditions for orthogonal and skewed intersections of the branch pipe axis and the main pipe axis, both with and without eccentricity.

2.The software can cut intersecting line ends at the branch pipe’s end, meeting the conditions for vertical and skewed intersections of the branch pipe axis and the main pipe axis, both with and without eccentricity.

3.It can cut inclined end faces at the ends of cylindrical pipes.

4.The software can cut welding elbows and “shrimp-shaped joints” with inclined cuts at both ends.

5.It can cut intersecting line ends where a branch pipe intersects a ring-shaped main pipe.

6.The software can cut square holes, waist-shaped holes, and elliptical holes (square and waist-shaped holes can have rounded corners) on the side of a cylindrical pipe.

7.It can perform steel pipe cutting.

8.The software can groove the pipe ends.

9.It can create pipe fittings such as elbows, tees, and other pipe joints.

Get A Free Quote

Products Categories

Fiber Laser Cutting Machine

Plasma Cutting Machine

Metal Pipe Cutting Machine

Laser Cleaning and Welding Machine

Spare Parts

Get A Free Quote

Light Square Round Tube Pipe Laser Cutting Machine Description

The Light Square Round Tube Pipe Laser Cutting Machine widely used in the cutting of pipeline structural parts in the construction, chemical, shipbuilding, engineering machinery, metallurgy, power and other industries. The CNC intersecting line cutting machine can very conveniently cut and process such workpieces without additional operation calculations and programming. You only need to enter the intersecting line, intersecting line holes and welding grooves of the pipeline in the pipeline intersecting system.

The Light Square Round Tube Pipe Laser Cutting Machine can automatically calculate and cut the contours of the intersecting line position, profile position edge, elbow, etc. It is mainly used in the processing of pipeline structural parts in the construction,

Data Sheet of Light Square Round Tube Pipe Laser Cutting Machine

1.Drive type and cutting method:

1	Steel tube transmission mode	The electric drive chuck rotates to match the longitudinal equipment operation
2	Cutting mode	Laser (depend on your request)
3	Lifting mode	Manual/Automatic
4	Cutting function	Intersecting line cutting

metal pipe	diameter : Square/Rectangle pipe=20mm-100mm;Round pipe:20mm-200mm
Pipe length	6000mm
rotation speed	0.1-25r/min
position accuracy	±0.1mm
running accuracy	±0.2mm
cutting speed	100-6000mm/min
input power	220±10%V AC50HZ/60HZ
tramsmission method	USB
Electrical components	CHINT
Programe software	AutoCAD/CAM
package size (LWH)	2500mm700mm1500mm

2.Working environment request:

1	Working voltage	AC220±10v
2	Input power	3.0KW
3	Working temperature	-10~50℃
4	Relative humidity	5%~90% no condensation

Note: Consumables of laser cutting head aslo can get from us.

Light Square Round Tube Pipe Laser Cutting Machine Video

Light Square Round Tube Pipe Laser Cutting Machine Application

The Light Square Round Tube Pipe Laser Cutting Machine has the characteristics of wide cutting range, fast cutting speed and high efficiency. It has certain flexibility, moderate equipment size, moderate disassembly difficulty, and is suitable for low-dust (dust-free is better) construction environment and less disturbed work site.

It has high precision, less slag, smooth cut surface and good verticality. It can be used for cutting a variety of metal pipes: metal pipe industry, stair handrails, road guardrails, metal structure buildings, bridge engineering and other industries.

Its main application is limited to the cutting of steel and thick plates, and it will gradually be replaced by plasma cutting in the cutting of thin steel plates. Plasma cutting has the characteristics of large cutting width, can cut all metal pipes, fast cutting speed, and high efficiency. The cutting speed can reach more than 10 meters/minute.

However, the level of laser cutting is higher than that of plasma cutting, and no secondary processing is required, which eliminates the cost of reprocessing.

Therefore, if you are looking for the most efficient pipe cutting machine, please choose a Light Square Round Tube Pipe Laser Cutting Machine.
